Features
- Lifetime warranty
- Standard package contains 5301 closer body, 5302 closer cover, 5303 main arm assembly, 5304 standard screw pack, 5900 parallel arm bracket, and 5902 SNB screw pack for 1-3/4 (44 mm) door
- Certifications: BHMA Certified ANSI A156.4, adjustable sizes 2 to 6 – Standard
- ADA Compliant ANSI A117.1 Accessibility Code only for adjustable sizes 1 to 4 – Optional UL/cUL Listed for up to 3 hours., UL10C Positive Pressure Rated, UL10B Neutral Pressure RatedMaterials: Aluminum alloy
- Cover: Full plastic cover and pinion cap Springs: Double heat treated steel, tempered springs
- Valves: Adjustable latching and sweep speed valves, Adjustable backcheck valve – Standard, Delayed action valve – Optional, Staked valves – Standard
- Handing: Non-handed
- Arms & Brackets: Tri-Pack: Regular, Parallel Arm, and Top Jamb Mount – Standard, 15% power adjustment in standard arm for regular and top jamb mount
- Door Thickness: 1-3/4 (44 mm)1-3/8 – 2-1/4 (36 mm – 57 mm) Optional
- Fasteners: Self-reaming, self-tapping wood and machine screws, Sex nuts and bolts
- Finishes: ALM, BRZ, DBZ, GOL, Rust inhibiting primer – Standard
- Notes: Full rack and pinion operation,Precision machined, heat treated steel piston, Triple heat treated steel spindle
